PLC based Computerised Hydrostatic Pressure Testing Equipment
As per IS 4984 and IS 4985 to check the creep rupture of pipe when subjected to internal pressure under a specified condition.
Pressure range : 0 – 100 bar*.
No. of stations : 8 nos.
Pressure input : Through compressed air having pressure upto 5 kg/cm.sq
Pressure output: through hydro-pneumatic pump.
Time range : 0 – 999.9 hours.
Panel mounting : Trolley with castor wheels.
Paint : Powder coated.
Power : 230 Volts, 50Hz, single phase.
Direct display through MMI : Set pressure, Actual pressure, Set time, Actual time, Set temperature and Actual temperature.
Graphic display and printout through PC : In addition to the above values Pressure & Temperature Vs Time graph could be obtained for any station by attaching a printer to the PC.
Analogue Hydrostatic Pressure Testing Equipment
As per IS 4984 and IS 4985 to check the creep rupture of pipe when subjected to internal pressure under a specified condition.
Pressure Range : 0 – 100 kg / cm sq*.
Time totalizer : Digital presettable with range upto 999.9 hours.
No. of station : 3 nos*.
Pressure input : Through compressed air having pressure upto 5 kg / cm sq.
Pressure output : Through hydro-pneumatic pump.
Panel mounting : Trolly with caster wheel.
Paint : Powder coated.
Power : 230V, 50 Hz single phase.
* Equipment with other capacities could also be supplied as per the requirement.
